| Max.Length Admitted between Centres B | 42” |
| Max.Length Admitted with 9” Chuck | 38 ¾” |
| Max. Diameter of Work | 10” |
| Max.Length Ground at one Setting A | 41” |
| Max. Lead Recommended | 12” |
| Min.Pitch Recommended | 60 T.P.I |
| Max. Helix Adjustment | 45° |
| Max. Capacity of Collet | 1 ½” |
| Max. including Taper per foot | 1 ½” |
| Relief | Variable between 0 & 5 mm |
| Min.Diameter of Internal Threads Ground | ¾” |
| Workhead Speed Range | 21 R.P.M to 39 R.P.M |
| Return Speed | Variable to 60 R.P.M |
| H.P. of Wheelhead Motor | 3 ½ / 1 ¼ |
| H.P. of Workhead Motor | ¾ |
| H.P. of Crusher Motor | 1/3 |
| Capacity of Coolant Pump | 12 Gallons per min. |
| Capacity of Coolant Tank | 30 Gallons |
| Max.Weight of work Recommended | 100 lb |
| Head Stock and Tail Stock Centres | No. 4 Morse |
